7720 Series

7720-32C

The following figure illustrates the components on the front panel of the 7720-32C.

7720-32C front panel view
  1. 32 40/100 Gbps QSFP28 ports
  2. 1 RJ-45 serial console port
  3. 1 USB Type-A port
  4. Two RJ-45 management ports:
    • MGMT2 - CPU and BMC (secondary)
    • MGMT1 - Direct to CPU (primary)

The back panel (not shown) includes dual redundant hot-swappable power supplies and six hot-swappable fan units.

The 7720-32C supports two internal Extreme Integrated Application Hosting (IAH) ports labeled as Insight ports, 1/s1 and 1/s2, used by IAH virtual machines. For conceptual information see Extreme Integrated Application Hosting. For configuration instructions to use internal IAH ports, see Virtual Services Configuration using CLI and Virtual Services Configuration using EDM.
